The European Pharmacopoeia (Ph. Eur.) is a single reference work for the quality control of medicines. Ph. Eur. contains norms, suggests analytical methods, and lists many properties that define quality control (QC) during the production of medicines, the raw materials used, and the instruments required to perform such tests. These official standards are legally binding in several countries – not only in Europe, but worldwide.

Raman spectrometers—especially handheld and portable instruments—are increasingly used for QC of medicines and raw materials (RMID). Instrument interfaces are user-friendly, requiring little technical expertise, and they provide flexible sampling options for most sample types with rapid, non-destructive measurements.

Metrohm’s Raman systems exhibit great flexibility—from see-through to standoff to immersion sampling.


An excerpt from the Ph. Eur. 2.2.48 Raman Spectroscopy chapter says:

https://s7e5a.scene7.com/is/image/metrohm/4421-800px?ts=1674212325657&dpr=off

For a look at RMID from start to finish, download our free four-part tutorial series here.


Handheld Raman for RMID in pharma and other regulated industries

Technological developments and their increasing adoption in the pharmaceutical industry prompted a revision of Ph. Eur. 2.2.48 which ensures the reliability of Raman results. The updated chapter 2.2.48 was published in the Ph. Eur. Supplement 10.7 (October 2021) and will ultimately take effect in April 2022.

While much of the Ph. Eur. 2.2.48 chapter has remained the same, the latest revision features:

  • new requirements for spectral resolution for qualitative Raman analysis using a suitable reference material
  • updated requirements for the Raman response-intensity scale
  • detailed procedures for the comparison of spectra



We will address these new requirements across our Raman spectroscopy product lines in the rest of this article.



Spectral Resolution

Handheld Raman instruments: MIRA P and NanoRam

All MIRA P and NanoRam devices (including both NanoRam and NanoRam-1064) for the pharmaceutical industry are designed and tested to meet stringent resolution requirements. During QC, the resolution of each instrument is tested to be less than 15 cm-1 against a secondary USP (US Pharmacopeia) reference standard of calcium carbonate according to ASTM E2529, which is the same procedure recommended in this newly released Ph. Eur. chapter.

The measured spectral resolution value for each instrument, along with its identifying serial number, is included in the instrument final test report. A certificate or final test report is packaged with the device and sent to the customer (starting in April 2022 for MIRA P). This resolution is fixed by the optical design of the instrument and is stable over time.

Portable Raman instruments: i-Raman series, QTRam, STRam, and PTRam

The instrument resolution for all of Metrohm’s portable Raman instruments from B&W Tek are factory-tested with calcium carbonate and displayed on final instrument test reports. The spectral resolution is dependent on the instrument design and defined for each specific instrument configuration. Depending on the instrument model, the spectral resolution is between 3.5–11 cm-1. Additionally, the instrument control softwares Vision and BWAnalyst have the performance test function that verifies spectral resolution using the 1001.4 cm-1 peak of polystyrene.

Handheld and portable Raman instruments from B&W Tek.

Response-Intensity Scale

Handheld Raman instruments: MIRA P, MIRA M-3, and NanoRam series

MIRA P, MIRA M-3, and NanoRam systems are designed for qualitative analysis, not for quantitative purposes. Therefore, this criterion is not a strict requirement for handheld Raman products.

However, the relative intensity response of MIRA P and NanoRam series instruments is calibrated with a NIST standard SRM calibration material (SRM 2241, SRM 2242) or NIST SRM 2241-traceable calibration standard to achieve better uniformity from instrument-to-instrument.

The NanoRam series instruments have an acceptance criterion for relative intensity response in the instrument performance validation in alignment with Ph. Eur. 2.2.48 and USP<858>. To pass the performance validation, <10% relative intensity error is required using the factory-supplied polystyrene cap.

Portable Raman instruments: i-Raman series, QTRam, STRam, and PTRam

The relative intensity response of these portable Raman instruments is calibrated using a proper NIST standard SRM calibration material to achieve better uniformity from instrument-to-instrument. Additionally, the Vision instrument control software includes the performance test function that verifies the intensities of several Raman peaks of polystyrene relative to its 1001.4 cm-1 peak, to a maximum variation of ±10% compared to the previous instrument qualification.


Comparison Procedures

For qualitative methods, additional information for identification has been defined.

While an experienced Raman spectroscopist can certainly compare spectra visually and assess sample validity based on peak location, fluorescence, saturation, and signal-to-noise ratio, the widespread implementation of Raman in the real world means that complex analysis must be done by the device and not the user. Statistical comparison methods are used primarily for identification of unknowns through correlation of a sample spectrum with library spectra. The software performs library searches and returns a Hit Quality Index (HQI) value indicating the level of correlation as defined by a user-defined threshold.

Chemometric methods rely on dimensionality-reduction methods that are performed by the software, such as Principal Component Analysis (PCA), where new sample data is compared within a multivariate model created from representative samples. This permits highly accurate verification of known materials according to how well a spectrum fits into the model limits, which are determined by a confidence interval. In the analysis of medicines and raw materials, chemometric methods are used to distinguish the quality and consistency of a material. MIRA P (and its dedicated software, MIRA Cal P) and NanoRam instruments use both statistical and chemometric methods for sample identification and verification based on the needs of the end-user.

Wavenumber accuracy requirements of Ph. Eur. 2.2.48

The Calibrate/Verify Attachment (CVA) shown here is a dual-ended accessory containing a toluene/acetonitrile ASTM standard for calibration/verification of the wavenumber axis and polystyrene for a second wavenumber verification according to Ph. Eur. 2.2.48.
The Calibrate/Verify Attachment (CVA) shown here is a dual-ended accessory containing a toluene/acetonitrile ASTM standard for calibration/verification of the wavenumber axis and polystyrene for a second wavenumber verification according to Ph. Eur. 2.2.48.

This chapter maintains the same requirements for Raman wavenumber accuracy and is consistent with the USP <858> and JP 2.26. All of Metrohm’s handheld Raman instruments meet these requirements. Users are recommended to run performance validation tests at regular intervals using polystyrene or another ASTM Raman shift calibration material.

Download our free White Paper below to learn more about instrument calibration, system verification, and performance validation.


Instrument Calibration, System Verification, and Performance Validation for Metrohm Instant Raman Analyzers (Mira)

Performance tests for Raman wavenumber accuracy are included the Vision and BWAnalyst softwares for the i-Raman series and other portable Raman products (STRam, QTRam, PTRam), with acceptance criteria in accordance with the pharmacopeial requirements.

Metrohm’s unique way of compliance with Ph. Eur. 2.2.48

Better representation of the material

ORS™ is Metrohm Raman’s proprietary method for moving the excitation laser in a pattern over a sample in order to collect more representative data from a larger area of the sample, especially on heterogeneous samples. All MIRA and MISA instruments are equipped with ORS.

https://s7e5a.scene7.com/is/image/metrohm/ORS_new?ts=1674212325813&dpr=off

Learn more about ORS by downloading the related Application Note here.


Improving verification with Orbital Raster Scan technology

For more details about how we comply, please check the U.S. Pharmacopeia Raman Chapters Updates page on the B&W Tek website. For more general information, download the General Compliance Statement for MIRA handheld Raman systems.


B&W Tek: U.S. Pharmacopeia Raman Chapters Update



For a more comprehensive look at raw material identification and verification in the pharmaceutical industry, read our related blog post.


Real World Raman: Simplifying Incoming Raw Material Inspection
